LCM0801A-FL-YBW-33V33 | 1×8 Character Display | Single Row Transflective LCD | Yellow/Green Backlight | STN (+) Positive Yellow/Green Display 3V
When powered up, the Longtech 8×1 character Liquid Crystal Display brings your data to life with dark pixels contrasted against a vibrant yellow/green background. This transflective LCD display is engineered to provide optimal visibility under a wide range of lighting conditions. In bright sunlight, the display uses its reflective layer to reflect ambient light back to the viewer, making the screen easy to see. In darker settings, the display’s backlight turns on to provide additional illumination. This ensures the display is always easy to read, regardless of the lighting conditions.
The wide operating temperature range from -20 to 70 degrees Celsius makes this LCD the perfect display for rough environments. The LCM0801A-FL-YBW-33V33 display provides an optimal view from the 6 o’clock direction and operates seamlessly at a 3.3V supply voltage. Compatible with Arduino and other development boards, this high-quality, single-line LCD is RoHS-compliant and has undergone rigorous quality tests to meet or exceed industry standards.
With a slim and compact design, this dot-matrix LCD can display a long string of characters with a scrolling feature that is not restricted to just eight characters. One of its distinguishing features is the built-in ST7066U controller making the operations smooth and efficient, which allows parallel communication with a 4-bit or 8-bit MPU interface.
| Number of Characters |
8 |
| Number of Rows |
1 |
| Display Format |
8×1 |
| Display Type |
STN (+) Yellow/Green |
| Display Mode |
Transflective |
| Outline L x W x H |
53.0mm x 24.2mm x 11.0mm |
| Viewing Area L x W |
35.0mm x 12.6mm |
| Active Area L x W |
32.80mm x 11.6mm |
| Supply Voltage |
3.3V |
| Backlight |
Side Yellow/Green |
| Interface |
Parallel |
| Compatibility |
Arduino and similar development boards |
| Controller Type |
ST7066U |
| Connection Type |
2×7 pins with 2.54mm pitch |
| Operating Temperature |
-20°C ~ 70°C |
| Storage Temperature |
-30°C ~ 80°C |
QUALITY STANDARDS
At Newhaven Display we strive every day to provide our customers with the highest quality products. This means Quality, Engineering, and Manufacturing teams are aligned to exceed your expectations.
Our customers should expect their products to meet or exceed the following standards:
All Products
| Reliability Testing |
Customers can expect all production parts to meet or exceed operational requirements over temperature, humidity, and vibration. |
| Glass Cleanliness |
Customers can expect glass to be protected by liners and presented mindful of cleanliness standards. This means glass will be clean of contaminants, fingerprints, and other foreign material. |
| Bezel Appearance |
Bezels will be uniformly painted free of foreign materials and distracting cosmetic blemishes. Our standards maintain a clean scratch-free surface. |
| PCB Appearance |
PCB’s are delivered with long-term reliability in mind. Finishes are free of bubbles, foreign contaminants, and meet all UL fire requirements. PCB materials will always be delivered within industry norms. PCB edges will be cleanly cut and void of burrs. |
| Soldering |
Soldering of all leaded and SMT components is consistent in providing the mechanical security and electrical connectivity. |
| Consistency |
Our manufacturing and inspection processes ensure product consistency from lot to lot. This means orders processed over the years will continually meet your expectations. We do this by exacting manufacturing specifications, with attention to detail in our processes, and by comparing to the golden units. |
| Product Integrity |
Quality in product manufacturing ensures integrity in construction. Customers can expect tight assembly without worry of loose parts or missing material. Our products will meet all environmental expectations including temp, humidity, & vibration conditions. |
| Glass Color |
While normal variations of glass color may occur (due to manufacturing tolerances), Newhaven Display maintains color compliance per internal approved color charts. These charts are maintained to ensure any minor glass deviations are identified and corrected as needed. |
| ESD Protection & Safety |
All devices are designed and handled in consideration of ESD protection. This includes ESD-SAFE packaging within anti-static bags, wraps, and trays. Customers are reminded to always follow ESD safety to best protect the devices. |
